| PART No. | Length L |
Travel T |
1395S Series Mounting holes (mm) | Slide weight (kg/pc) |
Load rating lbs. (kg)/pair |
|
|---|---|---|---|---|---|---|
| A | B | |||||
| 1400S-70 | 70 | 82.7 | ― | 50 | 0.040 | 22 (10) |
| 1400S-100 | 100 | 117.3 | 40 | 70 | 0.055 | 22 (10) |
| 1400S-125 | 125 | 141.9 | 50 | 95 | 0.069 | 22 (10) |
| 1400S-150 | 150 | 166.5 | 60 | 120 | 0.082 | 22 (10) |
