| PART No. | Length L |
Travel T |
2300 Series Mounting holes (mm) | Slide weight (kg/pc) |
Number in a box |
Load rating lbs. (kg)/pair |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | ||||||||
| IDS2300−200 | 200 | 134.4 | 145 | 160 | − | 145 | 160 | − | − | 0.16 | 60 | 53(24) |
| IDS2300−250 | 250 | 184.4 | 195 | 210 | 150 | 195 | 210 | − | − | 0.21 | 60 | 55(25) |
| IDS2300−300 | 300 | 221.7 | 245 | 260 | 190 | 245 | 260 | − | − | 0.24 | 60 | 57(26) |
| IDS2300−350 | 350 | 259.0 | 295 | 310 | 225 | 295 | 310 | − | − | 0.29 | 60 | 55(25) |
| IDS2300−400 | 400 | 296.3 | 345 | 360 | 265 | 345 | 360 | − | − | 0.33 | 60 | 53(24) |
| IDS2300−450 | 450 | 333.6 | 395 | 410 | 300 | 395 | 410 | − | − | 0.37 | 60 | 51(23) |
| IDS2300−500 | 500 | 370.9 | 445 | 460 | 337 | 445 | 460 | − | − | 0.41 | 60 | 44(20) |
